Parameter
|
Item |
Specification |
|
Film Structure |
14-Layer Metal-Target Triple-Silver Sputtered Base-Film |
|
Total Thickness |
3.0mil (76μm) |
|
Visible Light Transmittance (VLT) |
15%/70%optional |
|
UV Rejection Rate |
≥99% |
|
Infrared Rejection |
96%-99% (varies by VLT) |
|
Total Solar Energy Rejection (TSER) |
63%-70% |
|
Visible Light Reflectance (Interior) |
≤13% |
|
Color Fastness Level |
Grade 5 (highest) |
|
Operating Temperature |
-40℃ ~ 90℃ |
|
Standard Roll Size |
1.52m × 30m (60inch × 100ft) |
|
Warranty |
10 years |
Feature
Adopting high-vacuum triple-silver precious-metal magnetron sputtering technology, it achieves spectral-selective reflective heat insulation with long-lasting thermal rejection, and blocks over 99% of ultraviolet rays to protect occupants and vehicle interiors.
Its multi-layer dielectric stack structure reduces electronic signal interference. The low interior-reflectance design eliminates optical distortion and maintains clear vision to ensure driving safety at night.
Fabricated via fourteen-target precious-metal magnetron sputtering, the film features weather resistance and anti-oxidation properties, with guaranteed stable performance without discoloration within the warranty period.
Production Details
Product Qualification
The Triple-Silver Sputtered Metallic Series follows the standardized quality management system of ZR Zirui New Material and complies with relevant automotive window-film industry standards. Finished products undergo rigorous testing and pre-application trial-fitting records are kept.
The product meets industry-standard test specifications, with accurate traceable test records available for each individual batch. Raw material inspection, on-line process monitoring and finished-product sampling inspection are implemented throughout production to ensure consistent quality.
Authoritative third-party test reports can be provided upon request, and all performance indicators remain stable within the warranty coverage.
Deliver, Shipping and serving
Backed by ZR Zirui New Material's self-owned manufacturing base, we deploy robust raw-material governance and standardized production workflows. Both large-volume order fulfillment and bespoke brand customization are supported to satisfy varied demands from worldwide regional markets.
Flexible trade terms such as FOB, CIF and DDP are offered to match individual project needs. Leveraging extensive global freight partnerships, we deliver cost-optimized logistics packages tailored for overseas clients.
Our in-house technical team covers pre-sales consultation and after-sales support. Targeted technical assistance and timely feedback are guaranteed within a 24-hour response window.
FAQ
Q1: Will the triple-silver sputtered metallic film interfere with vehicle electronic signals?
A1: Optimized with multi-layer dielectric stacking, this triple-silver film greatly reduces signal shielding caused by metallic layers. Vehicle electronic signals remain unaffected under standard installation conditions. For new-energy vehicles, on-site testing per vehicle model is recommended prior to selection.
Q2: How is oxidation prevented for sputtered metallic film?
A2: Manufactured with fourteen-target precious-metal sputtering and precious-metal passivation protective structure, this product restrains silver-layer oxidation. It maintains weather-resistant stability without discoloration throughout the warranty period.
Q3: Which glass positions are suitable for triple-silver sputtered metallic film?
A3: It is primarily designed for automotive front windshields. For side and rear windows, selection shall be based on glass tint and reflectivity performance.
Q4: Can third-party test reports be supplied for this series?
A4: Standard COA (Certificate of Analysis) documents are issued for every production batch. Authoritative third-party test reports can be provided upon request.
