Windshield Shield‑6.5miL

Windshield Shield‑6.5miL

A practical solution for everyday windshield protection, this Windshield Shield‑6.5miL protection film combines excellent optical clarity with a water-repellent, contamination-resistant surface. Its stain-resistant and heat-activated self-healing properties help keep the windshield clean and smooth, while providing up to 90% UV rejection for added protection and driving comfort.
Send Inquiry
Description
Technical Parameters

Parameter


Item

Specification

Film Structure

Protective Liner + Topcoat + TPU layer + PS Adhesive +PET Releasing Liner

Total Thickness

6.5mil (165μm)

Hydrophilicity/Hydrophobicity

Hydrophobic

UV Rejection Rate

≥90%

Glossiness

≥146 GU

Elongation at Break

≥226%

Coating Elongation at Break

≥293%

Tensile Strength

≥31.58 MPa

Self-healing Property

100%

Haze

≤0.91

Light Transmittance

92.0%

Standard Roll Size

1.52m x 15m / Custom sizes available

Warranty

5 years




Feature

01.

Clear Optical Performance-Maintains a clean, unobstructed view through the windshield for confident everyday driving.

02.

Contamination Resistant-Helps reduce the adhesion of dirt, dust, and road contaminants, making routine cleaning easier.

03.

Stain Resistance-Resists common stains and water spots to help maintain a cleaner, clearer windshield surface.

04.

Heat-Activated Self-Healing-Minor surface marks can recover when exposed to heat or hot water, helping preserve a smooth appearance.




Production Details

WS6-1
WS6-2
WS6-3




Product Qualification


As a dedicated producer of functional films, Shaoxing Zirui New Material Technology Co., Ltd. leverages cutting-edge imported precision coating know-how and strict quality oversight to supply robust, high-performing film options for global buyers. Our main product range covers automotive window films, building architectural films and domestic surface protection films, alongside tailor-made offerings to fit varied application requirements.

We procure top-tier optical base substrates exclusively from thoroughly audited supply partners. All key manufacturing workflows, from functional layer coating, curing treatment, high-precision slitting through to final finished-roll packaging, are completed within our modern in-house production premises. Thanks to this full vertical production setup paired with a complete quality assurance framework, we achieve complete production traceability and consistently output functional films with unwavering quality across every single roll.

Crafted for automotive windshields,this Windshield Shield‑6.5miL protection film offers exceptional optical transparency, maintaining crisp, distortion-free sightlines for safe driving. Built-in high-performance hydrophobic functionality enables efficient water beading and shedding. Its anti-soiling and stain-repellent surface fends off grime and unwanted deposits, cutting down maintenance efforts significantly. Featuring thermal self-repair performance, light scuffs on the film surface can vanish upon exposure to heat or hot water. Designed for long-term outdoor exposure, it offers dependable shielding for windshields from airborne pollutants and everyday surface wear.

product-1268-481

1
2




Deliver, Shipping and serving


Professional Pre-Sales Support - Expert technical consultation and complimentary samples to help you evaluate and select the right solution with confidence.

Complete Technical Documentation - CoA, TDS and all essential technical documents are provided up front, accelerating your evaluation process and streamlining order handling from quotation to delivery.

Responsive After-Sales Support - Our support team responds to every quality-related inquiry within 24 hours, delivering professional, engineered solutions in full compliance with standard purchasing, storage, and installation conditions.




FAQ


Q: Will this Windshield Shield‑6.5miL protection film affect my visibility or cause distortion while driving?

A: Not at all. The Windshield Shield delivers outstanding optical clarity, featuring 92.0% visible light transmittance and a remarkably low 0.91% haze rating. Once professionally applied, it becomes virtually undetectable - no distortion, blurring, or rainbow artifacts will interfere with your view. Built on a premium TPU substrate known for superior dimensional stability, the film pairs with a specially formulated pressure-sensitive adhesive designed to preserve crystal-clear vision. Unlike budget PET-based alternatives, our TPU film sustains consistent optical performance even under extreme temperature fluctuations, giving you reliable, distortion-free visibility in every driving condition.

Q: Does the film work with windshield wipers, and will it get scratched over time?

A: Absolutely - the Windshield Shield is fully compatible with standard wiper systems. Its self-healing topcoat is built to bounce back from minor surface marks caused by wiper contact, road debris, or routine car washes. These light scratches vanish on their own at ambient temperature, or speed up with mild heat exposure. The film also delivers strong resistance against everyday abrasion thanks to its robust construction. That said, we do recommend maintaining your wiper blades in good shape and avoiding dry-wiping a dusty windshield, as heavy grit buildup can lead to deeper marks that go beyond the film's self-repair range.

Q: Can the film prevent windshield cracks or chips from stone impacts?

The Windshield Shield adds a robust protective barrier against road hazards. Its high-strength TPU construction works by absorbing and spreading out the force from flying stones and debris, greatly lowering the chance of chips and cracks reaching your glass. In many real-world scenarios, it stops minor impacts before they can damage the windshield beneath. That said, no protective film can promise 100% immunity - especially against high-speed or large projectiles. What it does offer is a meaningful reduction in risk, plus the added benefit of helping to hold small existing chips in place and prevent them from spreading further.

Q: Is the film compatible with heads-up displays (HUD), rain sensors, and heating elements?

A:Yes - the Windshield Shield is completely metal-free and optically transparent, meaning it won't disrupt HUD projections, rain sensors, lane departure cameras, or any other windshield-integrated electronic systems. The TPU material and adhesive layer are specifically engineered to withstand heated windshields and defrost elements without bubbling, peeling, or losing adhesion over time. For vehicles equipped with a HUD, the film's exceptional clarity ensures the projected image stays crisp and readable without any degradation. We do recommend professional installation to guarantee precise alignment around all sensor zones.

Q: What is the after‑sales procedure in case of quality‑related issues?

A: If you encounter a quality defect under proper storage, transportation, and professional installation, simply contact us with supporting evidence (photos, videos, or test reports). We guarantee a response within 24 hours and will provide a suitable solution-such as repair or replacement-upon verification.
