Parameter
|
Item |
Specification |
|
Total Thickness |
12.0mil (300μm) |
|
Visible Light Transmittance (VLT) |
86.2% |
|
UV Rejection Rate |
≥99% |
|
Infrared Rejection |
10.5% |
|
Total Solar Energy Rejection (TSER) |
14.2% |
|
Visible Light Reflectance (Interior) |
13.89% |
|
Visible Light Reflectance (Exterior) |
13.91% |
|
Shading Coefficient(SC) |
0.98 |
|
Standard Roll Size |
1.52m × 30m (60inch × 100ft) |
|
Warranty |
10 years |
Feature
12 Mil Enhanced Protection
Increased film thickness provides added strength and durability for demanding safety applications.
01
Advanced Impact Resistance
Reinforced PET construction and a zirconium-enhanced layer help withstand impact and maintain film integrity.
02
Glass Fragment Retention
Helps hold shattered glass together after breakage, reducing splintering and the risk of flying glass
03
High UV Protection
Helps block harmful UV radiation while providing added protection for occupants and interior furnishings.
04
10-Year Warranty
Reliable long-term performance for commercial and public architectural applications.
05
Production Details
Product Qualification
Shaoxing Zirui New Material Technology Co., Ltd. is a professional manufacturer of functional films, integrating advanced imported precision-coating technology with rigorous quality management. We specialize in the development and production of automotive films, architectural films, and household protective films, providing dependable performance across a variety of applications.
We procure premium optical PET base films from certified upstream suppliers to secure consistent raw-material quality. Core procedures such as functional coating, curing, maturation, precision slitting and finished-goods packaging are fully completed in-house, granting us full-process manufacturing control. Rigorous inspections are implemented at every critical checkpoint - from incoming material checks to final product testing - so every roll complies with our performance and reliability standards prior to shipment.
Our upgraded Security 12‑Mil High‑Security Window Film leverages our in-house precision-coating expertise and stringent quality protocols for enhanced glass safeguarding. Built with boosted tear-resistance and robust structural integrity, this upgraded film keeps shattered glass fragments secured upon forceful impact, minimizing risks of lacerations and property harm from flying shards. It elevates glass security against heavy impacts, harsh weather conditions and malicious tampering. Every finished roll goes through thorough quality verification to guarantee consistent performance and extended service life, well-suited for high-security-priority residential and commercial glass applications.
Deliver, Shipping and serving
Consultative Pre-Sales Support - Application-specific consultation and complimentary product samples are provided directly by our factory-based team, helping you pinpoint the ideal film solution for your market and performance requirements.
Complete Technical Documentation - CoA, TDS and all essential technical documents are provided up front, accelerating your evaluation process and streamlining order handling from quotation to delivery.
Responsive After-Sales Support - All quality-associated enquiries will get a reply within 24-hour timeframe, paired with professional technical advisory services. This is subject to proper adherence to official storage, manipulation and installation specifications.
FAQ
Q: Is this Security 12‑Mil High‑Security Window Film explosion-proof?
A: No. This product is not designed or certified as an explosion-proof film. However, it provides effective shatter-retention protection. When glass breaks due to impact, accidental force, or extreme weather, the film helps hold shattered glass fragments together, reducing the risk of flying shards and secondary injury. It provides an added layer of safety for homes, offices, public buildings, and commercial spaces with large glass surfaces.
Q: Can architectural window film be removed and replaced without leaving adhesive residue?
A: Yes. Our architectural window films are designed for clean removal and replacement when properly installed and maintained. The high-quality, eco-friendly adhesive provides secure adhesion during service while allowing the film to be removed with minimal residue. For replacement, professional installers can use controlled heat and specialized tools to soften the adhesive and facilitate efficient removal, helping protect the glass and its surface coating. When handled correctly, the process is clean, efficient, and minimizes disruption.
Q: Where can this film be applied?
A: This film is suited to most indoor glazing, excluding surfaces behind perimeter fencing. Typical placements: entrances, vestibules, busy corridors, shared spaces (cafeterias, auditoriums, libraries, gyms), plus classroom and staff-room doors.
Q: Do you accept custom orders?
A: Absolutely. We offer both OEM and ODM customization services. With our in-house R&D team, we can develop products tailored to your specific requirements - whether you provide detailed specifications, performance standards, or simply a concept, we work closely with you from formulation to finished product to bring your vision to life.
Q: What is the after‑sales procedure in case of quality‑related issues?
A: If you encounter a quality defect under proper storage, transportation, and professional installation, simply contact us with supporting evidence (photos, videos, or test reports). We guarantee a response within 24 hours and will provide a suitable solution-such as repair or replacement-upon verification.
